Investment Casting and 3D Metal Printing: A Complete Guide with TCL
Investment casting and 3D metal printing are two key manufacturing methods with distinct strengths. 3D printing excels at rapid prototyping, customization, and complex designs, while investment casting offers scalability, wide material choice, and smooth surface finishes. Instead of competing, they often complement each other—3D printing can create wax patterns to speed up casting or add features not possible with traditional methods. Industries like aerospace, automotive, and defense already use both, and hybrid manufacturing is emerging as the future, blending speed, flexibility, and reliability.
In modern manufacturing, two powerful methods stand out for producing high-quality metal parts:investment casting and 3D metal printing(additive manufacturing). Each has its own strengths, and when combined, they open new possibilities for industries ranging from aerospace to automotive. Instead of competing, these processes often complement one another.
What is 3D Metal Printing (Additive Manufacturing)?
- Minimal waste compared to traditional machining
- Ability to create complex internal channels or hollow parts
- Perfect for custom, low-volume, or rapid prototypes
Common additive manufacturing processes include SLM, DMLS, and binder jetting.
What is Investment Casting?
Investment casting, also known as lost-wax casting, is one of the oldest metalworking methods, refined over 5,000 years. It creates precise, near-net-shape parts with exceptional surface finish.
The process involves:
- Wax Pattern Creation – Wax models are formed using machine dies.
- Assembly & Gating – Patterns are joined to a central for efficient batch casting.
- Ceramic Shell Building – Layers of ceramic slurry and sand build a strong mould.
- Wax Removal – Heating removes the wax, leaving a hollow shell.
- Molten Metal Pouring– Alloys such as steel, titanium, bronze, or gold are poured in.
- Shell Removal – Once cooled, the shell is broken away to reveal the finished part.
Investment Casting and 3D Printing: Key Comparisons
| Factor |
Metal 3D Printing |
Investment Casting |
| Cost |
High machine price (metal 3D printer price = $100K-$2M+) |
Low per-part at scale |
| Speed |
Parts in hours/days |
Weeks (pattern creation) |
| Best For |
Prototypes, custom implants |
High-volume gears/valves |
| Material Choice |
20-30 metal alloys |
1,000+ alloys |
| Lead Time |
Faster prototypes (no tooling needed) |
Longer setup, faster production (once moulds exist) |
| Surface Finish |
Rough; needs machining (post-processing essential) |
Near-net shape (ready to use) |
| Part Size |
Limited by printer bed (max ~1m³ typically) |
Virtually unlimited (multi-ton parts possible) |
When to Use 3D Metal Printing
3D printing shines when speed and complexity matter most:
- Rapid prototyping in aerospace and automotive
- Medical implants tailored to each patient
- Lightweight, topology-optimised parts
- On-demand spare parts for obsolete components
Examples:
- GE’s LEAP LEAP fuel nozzle (19 parts reduced to 1)
- Bugatti’s 3D-printed titanium brake caliper
- Custom spinal cages produced in just 72 hours
When to Use Investment Casting
Investment casting remains the preferred choice when:
- Large production volumes are needed
- A wide range of alloys must be used
- High-integrity parts with smooth finishes are required
- Components exceed the size limits of 3D printing
Industries like aerospace, defence, and industrial machinery rely on casting for its repeatability, cost efficiency, and proven performance.
The Future: Hybrid Manufacturing
Here’s the thing—there doesn’t need to be a winner. Many manufacturers now combine both methods:
- to cut mould lead times by up to 80%
- to achieve designs once thought impossible
This hybrid approach is already used by leaders like Boeing, Siemens, and GE.
Conclusion
Both are essential in modern manufacturing.
- 3D printing delivers speed, customisation, and innovation.
- Investment casting ensures scalability, material variety, and exceptional surface finish.
- Together, they create a smarter, faster, and more cost-effective path forward.
Tamboli Castings Limited, enters at the concept phase, providing simulation-led Design for Manufacturing, Prototyping options, and Integrated machining with robust quality systems for ready-to-assemble parts.
Whether you need a fast learning loop or a scalable production plan, we help you choose (and combine) the right route to performance, cost, and lead-time targets.
